Pipe Fiber Laser Cutting Machine
The pipe fiber laser cutting machine is designed for round tube, square tube, and profile processing. The 6046G–6000W configuration below is provided as a reference for buyers comparing working size, travel, accuracy, and production footprint.
Models and Series
6046G Reference6000 WRound & Square Tube
Specifications
| Laser Type | Fiber laser |
|---|---|
| Reference Model | 6046G — 6000 W |
| Maximum Tube Size | Φ460 × 6000 mm |
| Round Tube Range | Φ10–Φ460 mm |
| Square Tube Range | 10–400 mm |
| MOQ | 1 set |
| Warranty | 1 year |
6046G — 6000 W Reference Specifications
| Parameter | Reference Value |
|---|---|
| Equipment Model | 6046G — 6000 W |
| Maximum Tube Cutting Size | Φ460 × 6000 mm |
| Round Tube Range | Φ10–Φ460 mm |
| Square Tube Range | 10–400 mm |
| Laser Power | 6000 W |
| Maximum Carbon Steel Thickness | ≤20 mm |
| Maximum Stainless Steel Thickness | ≤16 mm |
| X-axis Rapid Speed | 80 m/min |
| X-axis Travel | 550 mm |
| X-axis Positioning Accuracy | 0.05 mm |
| X-axis Repeat Positioning Accuracy | 0.03 mm |
| Y-axis Rapid Speed | 80 m/min |
| Y-axis Travel | 6050 mm |
| Y-axis Positioning Accuracy | 0.05 mm |
| Z-axis Travel | 200 mm |
| Z-axis Positioning Speed | 10 m/min |
| X/Y Transmission | Gear rack / helical gear |
| Z-axis Transmission | Ball screw |
| Maximum Acceleration | 0.7 G |
| Cutting Bevel | ≤1° |
| Data Transfer | USB |
| Network | RJ45 |
| Minimum Setting Unit | 0.001 mm |
| Machine Noise Level | ≤80 dB |
| Reference Equipment Size | 9000 × 1500 mm |
| Reference Equipment Weight | 5 t |
Reference configuration. Final specifications are subject to confirmed requirements and quotation.
Product Advantages
- Large configurable tube diameter and working length
- Suitable for round, square, and profile processing
- Accurate positioning with rack and ball-screw transmission
- Industrial control and data-connectivity options
Application Scenarios
- Metal furniture and fitness equipment
- Automotive and agricultural components
- Steel structures and pipe fabrication
- Industrial equipment frames
Customizable Options
- Laser power and tube length
- Chuck configuration and tube range
- Automatic loading and unloading
- Cutting software and nesting system
- Voltage, branding, and interface language
Packaging & Delivery
Packaging
The machine bed, chuck, laser source, and electrical components receive export-grade protection and reinforced fixing.
Delivery
Typical production time is 20–45 days after the final configuration is confirmed.
